LCD 252 TV Wall Mount

Adjustable TV Wall Bracket for Most 17-37 Inch TVs, 30kg Weight Capacity Max VESA 200x200mm, Solid and Sturdy TV Bracket with Swivel Tilt Level Tool and Cable Ties
Availability:
Quantity:


Product Overview


The LCD 252 TV MOUNT is a heavy-duty wall mount designed for 42–85 inch LCD, LED, and OLED TVs, prioritizing secure, space-saving installation. With a fixed low profile (2.5 cm from the wall) and high-strength steel construction (2mm thickness), it supports up to 80 kg (176 lbs) and fits VESA patterns from 200×200 mm to 800×500 mm. Its slim design—blending with wall decor—makes it a popular choice for home theaters, commercial lobbies, and conference rooms where a seamless, unobtrusive look is desired.


Product Features


Secure Wall Attachment:

The mount requires stud mounting (16–24 inch spacing) or concrete anchors (included) for stability, with a reinforced dual-backplate design (2mm steel) that distributes weight across 4–6 wall points. Included 10mm diameter lag bolts (50mm length) ensure a tight fit in wooden studs, while M10 concrete bolts (80mm length) secure it to brick or concrete walls.


VESA Compatibility:

It accommodates VESA patterns from 200×200 mm (small 42-inch TVs) to 800×500 mm (large 85-inch models), with sliding brackets (adjustable ±5 cm horizontally) for alignment if studs are misaligned. The brackets feature quick-release tabs for easy TV removal during wall painting or maintenance.


Installation Features:

A built-in bubble level (±0.5° accuracy) ensures straight mounting, while the pre-drilled backplate (with 16mm hole spacing) simplifies stud alignment. The package includes a magnetic Phillips screwdriver to prevent small screws from falling during installation.


Safety & Heat Management:

The anti-theft security screws (Torx T20 head) prevent unauthorized removal—ideal for commercial settings like hotels or airports. The open-frame design allows 360° airflow behind the TV, reducing overheating risk for 4K/8K models that generate more heat during extended use.


Applications


Home Theaters: Creates a seamless look for 75–85 inch TVs as the focal point, with the low profile (2.5 cm) minimizing distraction from the viewing experience.

Commercial Lobbies: Displays digital signage in airports, malls, or hotels with a clean, unobtrusive mount that complements interior design.

Conference Rooms: Supports large presentation screens (65–85 inches) for audience viewing in medium to large spaces (50–200 attendees).

Apartment Complexes: Used in common areas (e.g., lounges, gyms) for resident announcements or entertainment, with security screws preventing theft.

Sports Bars: Mounts large TVs (75–85 inches) for viewing by patrons, with the slim profile maximizing wall space for multiple screens.


FAQ


Q: Can it be mounted on drywall without studs, especially for smaller TVs?

A: No, even for 42-inch TVs, drywall alone cannot support the weight over time. TVs over 55 inches require stud or concrete mounting; failure to do so may result in mount failure and TV damage.

Q: What is the distance from the wall when installed, and does this affect TV ventilation?

A: The TV sits 2.5 cm (1 inch) from the wall—close enough for a sleek look but with sufficient gap (exceeding most TV manufacturers’ 1cm minimum ventilation requirement) to allow heat dissipation.

Q: Does it fit curved TVs, and will the mount damage the curved screen?

A: Yes, it supports curved TVs up to 85 inches (e.g., Samsung Q80C curved), provided the weight (≤80 kg) and VESA pattern match. The padded mounting brackets (3mm foam) prevent scratches on curved edges.

Q: What tools are needed for installation, and is professional help recommended?

A: A drill (with 10mm masonry bit for concrete), socket wrench, and Torx T20 driver are required. Professional installation is recommended for 75+ inch TVs to ensure proper alignment and safety, though DIY installation is feasible for smaller models with proper tools.


TV mount JYLCD-252-1
